Facilities
Layout
* The above layout is based on the completion of the final expansion project.
Berth
Classification
Berth #1
Berth #2
Berth #3
Berth #4
Berth #5
Berth #6
DWT
120,000 DWT
100,000 DWT
60,000 DWT
60,000 DWT
30,000 DWT
10,000 DWT
Type
CPP
LNG
CPP
CPP
CPP
LNG
* Berth #1, #3, #5 : Planned to construct
Storage Tank
LNG Tank
Name
Capacity
Type
TK-TA01
215,000m³
Full containment
TK-TB01
215,000m³
Full containment
TK-TC01
215,000m³
Full containment
OIL(CPP) Tank(cone down bottom)
Name
Storage Type
Capacity
Type
TK-T101
CPP
25,000m³
DRT
TK-T102
CPP
40,000m³
DRT
TK-T103
CPP
40,000m³
DRT
TK-T104
CPP
30,000m³
DRT
TK-T105
CPP
30,000m³
DRT
TK-T106
CPP
25,000m³
DRT
TK-T107
CPP
20,000m³
DRT + IFR
TK-T108
CPP
20,000m³
DRT + IFR
TK-T109
CPP
20,000m³
DRT + IFR
TK-T110
CPP
10,000m³
CRT + IFR
TK-T201
CPP,
Blending Stocks
5,000m³
CRT + IFR
TK-T202
CPP,
Blending Stocks
5,000m³
CRT + IFR
* CPP(Clean Petroleum Product) : Naphtha, Gasoline, Diesel, Jet fuel, Kerosene, etc.
